CRYSTALLIZERS
Crystallizers for controlled crystal formation in food production
Crystallization is an important process in food manufacturing, influencing the texture, consistency and physical properties of many products. Crystallizers are used to control the formation and growth of crystals by regulating processing conditions such as temperature, cooling rate, mixing and, where applicable, the introduction of seed crystals.
The required crystal structure depends on the product and its intended characteristics. In some applications, the aim is to obtain fine, evenly distributed crystals for a smooth texture. In others, crystal size and growth must be controlled to achieve a specific consistency or product structure.
How crystallization is controlled
Crystal formation generally involves two stages: nucleation, when small crystal nuclei first appear, and crystal growth, when additional material deposits onto their surfaces. The relationship between these stages determines the final crystal size and distribution.
Temperature is one of the main factors influencing crystallization. Cooling a solution can create the conditions needed for crystals to form, while the cooling rate affects how many nuclei develop and how large the crystals become. Mixing helps distribute temperature and material throughout the product and can support more uniform processing.
In processes that use seed crystals, finely formed crystals are introduced to provide nucleation points. This can help guide further crystal formation and improve consistency between batches. The appropriate conditions depend on the composition of the product and the desired result.
Crystallizers for different production processes
Crystallization equipment can be designed for batch or continuous operation. Batch crystallizers process a defined quantity of product in a vessel, allowing the operating conditions to be adjusted for individual recipes and production cycles. This arrangement can be suitable for smaller production volumes or applications requiring flexibility.
Continuous crystallization systems process material as it moves through the equipment, maintaining controlled conditions during ongoing production. They are intended for processes where a steady product flow and consistent operating parameters are required.
The actual configuration of a crystallizer depends on the product, processing method and production capacity. Heating or cooling arrangements, agitation and temperature control may differ considerably between applications.
Applications in food processing
Crystallization is used in several areas of food production, although the process requirements vary significantly.
In honey processing, controlled crystallization is used to produce creamed honey with a smooth, fine-grained structure. The formation and distribution of small glucose crystals determine the characteristic spreadable consistency of the finished product.
In confectionery and sugar processing, crystallization influences the texture and structure of products such as fondants and sugar-based preparations. Control over crystal formation is important for achieving the intended consistency and preventing an undesirable coarse texture.
Crystallization also plays a role in the processing of syrups, sweeteners and other concentrated solutions, where crystal formation can affect product stability, appearance and handling properties.
Selecting crystallization equipment
The choice of crystallizer depends on the material being processed, the required crystal characteristics and the intended production capacity. Important considerations include the product composition, operating temperature, cooling requirements, mixing arrangement and whether the process uses seed crystals.
Batch or continuous operation should be selected according to the production workflow and the degree of flexibility required. The equipment must provide suitable control over the conditions that influence nucleation and crystal growth, as these directly affect the properties of the final product.
FoodTechProcess offers crystallization equipment for food processing applications. To identify a suitable solution, provide details of the product, desired crystal structure, batch size or throughput, and the processing conditions required.
Equipment for the production of creamed honey, soufflé honey, whipped creamy honey. The machine is produced both in atmospheric and vacuum versions, the loading capacity ranges from 70 to 3500 kg of honey.
- Material: Stainless steel
- Principle of operation: Batch mode
- Country of origin: Slovakia
The atmospheric unit for whipping and creaming honey, featuring a new design with gravity mixing, represents the second generation of the successful CH Light creaming unit model. Gravity mixing honey is 40% more effective than traditional methods, particularly in the production of cream honey, where the mixing mode and cyclogram play crucial roles. The slanted design aids in quickly emptying the work tank with minimal product loss.
- Sloped design - 40% more efficient mixing
- Powerful agitator drive
- Collapsible frame mixer with movable scrapers made out of fluoroplastic
- Lid opening sensor - a guarantee of high safety for the operator
- Material: Stainless steel
- Principle of operation: Batch mode
- Country of origin: Slovakia
- Volume: 400l/600 kg
- Total power, kW: 1,5
- Voltage: 380-400V
The price is set for the basic version of the vacuum evaporation unit with basic controls (mixer motor switch) and without additional options. The control unit is customized based on individual customer requirements. The pump is also selected separately depending on the product.
A compact vacuum evaporation unit that allows you to concentrate solutions, mixtures, and various products by evaporating the solvent. A modular version based on the basic version of the 110/100 vacuum reactor.
- Gravity mixing - 25% more efficient
- Reinforced agitator design with no blind spots
- Bottom ball valve with no dead zones
- Condensation and secondary vapor removal system
- Easy to disassemble mixing device
- Large heat exchange area
- Ability to measure and monitor condensate volume (optional)
- Material: Stainless steel
- Engine power, kW: 0,25
- Principle of operation: Continuous mode
- Country of origin: Slovakia
- Volume: 100l
- Voltage: 220-230V
- Max vacuum: -0,8 Bar
- Working volume: 50-80l
- Condensing capacity, l/h: 45-55
- Steam consumption, kg/h: up to 150
The vacuum evaporation unit is specially designed for thickening dense food products in industrial quantities. The evaporator can be used for the production of thick syrups, caramel masses, dense fruit masses, as well as for the production of pectin, or heat-stable fillings with a high productivity.
- High performance
- Rotary spraying system with a powerful electric drive
- Evaporation in a thin layer with a large heat transfer area
- Low investment installation costs
- Tangential entry for product swirling
- Material: Stainless steel
- Principle of operation: Batch mode
- Country of origin: Slovakia
- Voltage: 380-400V
Plant for evaporating, concentrating and crystallizing solutions. Vacuum evaporator ensures a complete separation of the solution into a solid fraction and pure water.
The vacuum crystallizer-cooler is specifically designed for sweetened condensed milk. Crystallization with cooling is one of the most important stages in the production of condensed milk according to GOST and is necessary before dosing and packing the finished product.
- After crystallization, condensed milk has a delicate structure with small crystals
- Condensed milk has a homogeneous shape and attractive consumer properties
- The shelf life of condensed milk is extended without changing the quality of the product
- Material: Stainless steel
- Principle of operation: Batch mode
- Country of origin: Slovakia
- Volume: 100l/ 300l
- Voltage: 380-400V
- Max vacuum: -0,8 Bar
The cylindrical drum rotary machine is designed for drying and crystallizing liquid and paste food products into solid crystals.
- Compact tabletop design
- Automatic knives for cutting the product film
- Adjustable product layer thickness when applied to the drum
- Adjustable drum rotation speed to control drying time
- Material: Stainless steel
- Principle of operation: Continuous mode
- Country of origin: Slovakia
An evaporator concentrator-crystallizer is a multifunctional unit that concentrates liquids by evaporating water and inducing crystallization for the production of concentrated solutions or crystalline products.
- Material: Stainless steel
- Working volume: up to 6000 L
- Geometric volume: 6500 l
