PASTEURIZERS
Industrial pasteurization equipment for controlled heat treatment of food products
Pasteurization is one of the most widely used thermal processes in the food industry. It involves heating a food product to a defined temperature for a specified period to reduce pathogenic microorganisms and spoilage organisms, making the product safer and helping extend its usable shelf life.
Pasteurizers are designed to carry out this treatment under controlled conditions. Temperature, holding time and subsequent cooling must be carefully matched to the product, its composition, acidity, viscosity and microbiological requirements. The objective is to achieve the required microbial reduction while limiting unnecessary exposure to heat that could affect flavour, colour, texture or nutritional characteristics.
Pasteurization is used for much more than milk. It is an important processing stage in the production of juices, fruit preparations, sauces, liquid food products and various other perishable foods. Depending on the product and production capacity, treatment can be performed in batches or continuously as part of an automated processing line.
How the pasteurization process works
The basic pasteurization process consists of three main stages: heating, holding and cooling.
- Heating: The product is brought to the required pasteurization temperature using a suitable heating system. The rate of heating and the temperature reached depend on the product and the selected process.
- Holding: The product remains at the target temperature for a specified period. This holding time is essential to achieving the intended reduction of microorganisms.
- Cooling: After the heat treatment, the product is cooled to a suitable temperature for subsequent processing, filling or storage. Rapid and controlled cooling helps limit further quality deterioration and microbial growth.
The required temperature and holding time are not universal. Different products require different treatment conditions, and the process must be validated against the relevant food safety requirements. Product flow, viscosity and the presence of solid particles can also influence how heat is transferred and whether the entire product receives an adequate treatment.
It is also important to distinguish pasteurization from sterilization. Pasteurization reduces targeted microorganisms but does not necessarily destroy all microbial spores. Pasteurized products may therefore require refrigerated storage, hygienic filling or additional preservation measures, depending on their characteristics and the process used.
Types of pasteurizers
Pasteurizers are available in different configurations, with the main distinction being how the product is processed and how heat is transferred.
Batch pasteurizers
Batch pasteurizers treat a defined quantity of product in a vessel. The product is loaded, heated to the required temperature, held for the specified time and then cooled. Depending on the design, the vessel may include an agitator to improve temperature distribution and prevent local overheating.
Batch systems are particularly practical for smaller and medium-sized producers, facilities with several product recipes and operations where production volumes vary. They are commonly used for dairy preparations, sauces, fruit products and other foods that can be processed in a heated vessel.
Continuous pasteurizers
Continuous pasteurizers process product as it flows through the equipment. The product is heated, maintained at the required temperature for a controlled residence time and then cooled. These systems are suitable for regular production volumes and can be integrated into automated processing lines.
Depending on the product, heat exchangers may be used to transfer thermal energy efficiently. Plate heat exchangers are commonly suitable for relatively low-viscosity products without large particles, while tubular or other specialized designs may be better suited to more viscous products or products containing suspended solids.
Pasteurizers for viscous and particulate products
Not all food products behave like milk or juice. Thick sauces, fruit preparations and products containing pieces of fruit or other ingredients require equipment that can handle their viscosity and physical structure while ensuring uniform thermal treatment.
The choice of heating surface, product movement and flow arrangement is particularly important in these applications. Equipment must be selected so that heat reaches the entire product effectively without excessive mechanical stress or damage to solid ingredients.
Applications in the food industry
Pasteurization is used across many food processing sectors, with treatment conditions adapted to the specific product.
Dairy processing
Milk and cream are among the best-known applications of pasteurization. Heat treatment reduces pathogenic microorganisms while preserving the characteristics required for further processing or consumption. Pasteurization is also used at different stages in the manufacture of certain dairy products and preparations.
Juice and beverage production
Fruit juices and other beverages can be pasteurized to reduce microbial activity and improve storage stability. The process must be adapted to the acidity, composition and sensitivity of each beverage, particularly where preservation of fresh flavour and colour is important.
Sauces, dressings and condiments
Pasteurization can be used for liquid and semi-liquid products such as sauces, vegetable preparations and dressings. Their viscosity, oil content, acidity and formulation influence the required thermal treatment and equipment configuration.
Fruit and vegetable processing
Fruit purées, pulps, concentrates and other preparations may undergo pasteurization before filling or further processing. The equipment must be appropriate for the consistency of the product and any suspended fruit particles.
Prepared and processed foods
Certain liquid and semi-liquid components of prepared foods, including soups, sauces and fillings, can be pasteurized as part of their production process. The required treatment depends on the product formulation, packaging method and intended storage conditions.
Integrating pasteurization into a production line
In industrial food manufacturing, pasteurization is often one stage of a larger processing sequence. Products may first undergo preparation, mixing, homogenization or filtration before entering the pasteurizer. After heat treatment and cooling, they can proceed to filling, packaging or further processing.
The arrangement of this equipment depends on whether production is batch-based or continuous. Continuous systems can be connected directly to upstream preparation and downstream filling equipment, while batch pasteurizers offer greater flexibility when working with different recipes or smaller production runs.
Process monitoring is essential in either configuration. Reliable temperature measurement, control of holding time and appropriate product flow are necessary to ensure that the intended treatment conditions are consistently achieved.
Choosing the right pasteurizer
Selecting a pasteurizer requires consideration of both the product and the intended production process. A machine suitable for milk may not be appropriate for a thick sauce or a fruit preparation containing pieces of fruit.
Important factors include:
- Product characteristics: Viscosity, acidity, fat content, suspended particles and sensitivity to heat.
- Production capacity: Required hourly throughput or batch volume, including expected variations in production.
- Temperature and holding time: The treatment conditions required for the particular product and applicable food safety standards.
- Heating and cooling systems: The required heating rate, cooling capacity and possibilities for heat recovery.
- Processing configuration: Batch or continuous operation, depending on production volume and product variety.
- Cleaning and hygiene: Accessibility of product-contact surfaces and compatibility with the required cleaning procedures.
- Line integration: Compatibility with mixing tanks, homogenizers, heat exchangers, filling machines and other upstream or downstream equipment.
FoodTechProcess offers pasteurization equipment for different food processing requirements, helping manufacturers apply controlled thermal treatment to dairy products, beverages, sauces, fruit preparations and other foods. The appropriate configuration depends on the product, required capacity and production method, with the aim of achieving reliable pasteurization while maintaining the desired quality of the finished product.
A compact electric pasteurizer with a heating power of 5 kW is used for long-term batch pasteurization of milk, which includes heating milk to a temperature up to 100 degrees C and maintaining it for a selected period of time. The milk pasteurizer can also be used in the form of a Milk pot to heat milk for feeding calves.
- High heating power (5 kW) on a 220 V single-phase connection
- Stirrer with bottom scrapers that prevents milk from burning when directly heated
- Direct electric heating with a multi-stage power switch
- Hygienic design for simple and easy cleaning
- Simple system for removing and lifting the top hatch with an agitator
- Absence of blind spots where bacteria can grow
- Heating: Electric
- Material: Stainless steel
- Engine power, kW: 0,18/ 0,25
- Heating power, kW: 5
- Principle of operation: Batch mode
- Volume: 50l/ 100l/ 150l
- Outlet valve, inches: 6/4
- Diameter, mm: 400/ 500/ 600
The price is indicated without the heating and cooling sources
The continuous heat treatment and filtration unit is suitable for processing products of various viscosities, such as honey, jam, baby food, sauces, ketchup, tomato soup and many other products. Depending on the model, it can have a productivity ranging from 250 up to 2000 kg/hour.
- Universal application for continuous pasteurization
- Suitable for pasteurization of heat-sensitive products
- Ideal solution for thick and viscous products
- For short-term pasteurization followed by cooling
- Productivity: 250 kg/h/ 500 kg/h/ 1000 kg/h/ 2000 kg/h
- Principle of operation: Continuous mode
- Country of origin: Slovakia
The electric pasteurizer is ideal for the heat treatment of various fruits, including apples, pears, blackberries, strawberries, blueberries, elderberries, currants, carrots, greens, quince, beets, sea buckthorn, rowan berries, and onions.
- Material: Stainless steel
- Principle of operation: Continuous mode
The long-term pasteurization tank is a compact solution for the heat treatment of milk in order to disinfect the microflora and eliminate harmful microorganisms. This unit belongs to the category of long-term pasteurization systems, heating milk between 63 and 95 degrees Celsius, and maintaining it at a specific temperature for a set period of time. The special design allows not only for pasteurization of milk in the flow, but also for sequential cooling, by feeding cold water into the heat exchanger after heating.
- External forced circulation with a heat exchanger
- Highly efficient steam heating via the heat exchanger
- Can also be used as both a pasteurization and cooling unit
- High-performance milk pump
- Compact vertical design
- Heating: Steam
- Material: Stainless steel
- Principle of operation: Batch mode
- Volume: 1000l
This tabletop electric milk pasteurizer is designed for controlled thermal processing of milk and dairy products in small and medium-sized dairy processing factories. It is equipped with a built-in heating system, an electric mixer, and a hygienic release valve, ensuring uniform, slow pasteurization of milk at approximately 60-65°C for usually around 30 minutes. This mode is ideal for cheesemaking at home or in small-scale production facilities.
- Available in 50 L, 100 L, and 150 L capacities.
- Jacket heating and integrated water heating system
- Continuous mixing with an agitator
- Large-diameter bottom outlet valve for hygienic and quick emptying
- Removable lid with a mixer and protective grill
- Compact tabletop design
- Heating: Electric
- Material: Stainless steel
- Heating power, kW: 3/ 6/ 12/
- Country of origin: Slovakia
- Volume: 50l/ 100l/ 150l
The stated price does not include the steam generator
The unique sectional cooking kettle is intended for high-performance cooking/blanching/frying of a wide range of products with subsequent cooling to avoid damaging their structure. An essential part of this technology is the efficient cooling section, necessary for halting the cooking process after unloading. This function is also necessary when processing vegetables to the "aldente" state, when vegetables retain their structure and natural color after thermal treatment. This model provides heating by direct injection of purified steam into the heating section (steam generator - option).
- Suitable for cooking small-sized products
- Fast and intense heating due to direct steam injection
- Intensive hydro-stirring
- Automatic basket lifting system
- Material: Stainless steel
- Country of origin: Slovakia
- Volume: 2x250l/ 3x250l
- Voltage: 380-400V
- Working volume: 2x175l/ 3x175l
Milk pasteurizer for small and medium-sized enterprises, designed to carry out the pasteurization process of milk and other liquid products.
- Precision and stability of temperature control
- Maintaining the set temperature
- Uniform heating
- Heating: Electric
- Material: Stainless steel
- Heating power, kW: 6
- Principle of operation: Batch mode
- Type of equipment: Individual machine
- Country of origin: Slovakia
- Volume: 100l/ 300l
The Batch Pasteurizer BP 400 is designed for controlled heat treatment of food products in batch production, including vegetables, fruits, sauces, ready-made foods, and products packed in jars. Two 200-liter baths with automatic temperature control provide flexible and repeatable pasteurization, while the basket system and electric crane ensure convenient product handling.
- Two separate 200-liter pasteurization baths
- Automatic temperature control
- Suitable for jars, containers, and loose food products
- Suitable for vegetables, fruits, mushrooms, sauces, preserves, and ready-made foods
- Electric crane for convenient basket handling
- Maximum heating temperature of 90°C
- Easy-to-clean stainless-steel construction
- Separate bath heating available as an option
- Heating power, kW: 48
- Type of equipment: Individual machine
- Country of origin: EU
- Weight: 300 kg
- Voltage: 380-400V
- Geometric volume: 400 l
The MAK Milk pasteurizer is a 100-liter, double-walled batch processing unit designed for heating and stirring milk and other liquid or semi-liquid dairy products. The unit employs a combined heating system: direct electric heating at the base (6.5 kW power) transferring heat through a multi-layer ("sandwich") bottom, and gentle indirect air heating across the entire cylindrical surface of the processing vessel. The special double-walled design also significantly reduces heat loss and enhances operator safety.
- Agitator attachment features scrapers for the vessel bottom and walls, ensuring continuous product movement across heated surfaces.
- Interchangeable mixer attachment system allowing for the quick replacement of a scraper mixer with a cheese curd cutting blade (optional).
- Available with either manual six-stage heating control or an automatic digital PID temperature controller, timer, with adjustable stirring speed.
- Material: Stainless steel
- Heating power, kW: 6,5
- Principle of operation: Batch mode
- Country of origin: Slovakia
- Volume: 100l
The price is indicated with a semi-automatic control panel
The vacuum cooking kettle is designed for use in public catering establishments (restaurants, hotels, catering companies) and small manufacturing businesses. This equipment enables boiling, blanching, frying, evaporation, pasteurization, mixing or stirring.
- A unique multifunctional device
- Possibility to cook/fry under atmospheric or vacuum conditions
- Laboratory version of a Vacuum Fryer
- Built-in condensation and secondary steam removal system
- Intense electric heating
- Sectional basket with a lid
- Built-in system for separating and removing excess liquid from the product
- Heating: Electric
- Material: Stainless steel
- Heating power, kW: 5
- Volume: 20l
- Oil volume: 8l
- Voltage: 380-400V
- Max vacuum: -0,8 Bar
The pasteurization kettle with manual tilting is a modern device designed for gentle heat treatment of milk and dairy products, which allows for their effective pasteurization, extends shelf life and increases safety, while preserving the original taste and nutritional values. The 6-stage heating regulation of the powerful integrated heater, allows the milk to be reliably pasteurized directly in the container with a sandwich bottom, ensuring even heat distribution.
- Ideal solution for small-scale and home production of dairy products
- Removable lid for easy inspection and manual mixing of the product
- Option to equip it with a drain valve for discharging liquid products
- Even heating without burning thanks to the sandwich bottom
- Easy connection to a single-phase 230 V power supply
- Material: Stainless steel
- Heating power, kW: 2,6 / 6,5
- Volume: 30l/ 50l/ 100l
- Voltage: 380-400V
The cheese boiler is used in the dairy industry for the production of cheese grains during the production of natural hard, semi-hard, soft cheeses, and other cheese or curd products. The cheese maker is equipped with a special knife-mixer (lyre) for cutting the cheese curd. Suitable for both small and large scale production. Using this cheese-cooking boiler you can also pasteurize other dairy products, produce yogurt, cottage cheese kefir, fermented baked milk, varenets, sour cream and more.
- Material: Stainless steel
- Operation mode: Automatic
- Principle of operation: Batch mode
- Country of origin: Slovakia
- Working volume: 300 l
A 15-liter pasteurizer with a water bath that has a flat bottom and two canning racks, featuring a large capacity and made out of food grade 304 stainless steel.
- Material: Stainless steel
- Principle of operation: Batch mode
The multifunctional cooking and pasteurization kettle with manual tilting is a simple device designed for the entire jam production process: from cooking the fruit mixture to the subsequent pasteurization of finished products directly in jars. It allows you to prepare the product in a container and then, using an additional basket, pasteurize the filled jars without the need for any additional equipment.
- 6-stage regulation of the built-in heating allows you to set the optimal conditions for cooking the fruits and subsequent pasteurization without the risk of burning or loss of quality.
- The manual tilting mechanism with a three-stage adjustment and a maximum tilt angle of 110° ensures convenient emptying of the container and dosing of the finished product with virtually no losses.
- Heating: Electric
- Material: Stainless steel
- Heating power, kW: 2,6 / 6,5
- Volume: 50l/ 100l
The universal bath pasteurizer is used for processing a wide range of different food products, such as ready meals, sausages, hams or liquid products. Effective temperature regulation and a hygienic stainless steel design.
Beverage Pasteurizer SB 750 refers to chamber types of pasteurizers used to pasteurize bottled beverages.
- Material: Stainless steel
- Principle of operation: Batch mode
The professional cooking vat is designed for dairy products processing. The machine can be used by farms and small dairy factories.
Please check out the new updated version of our 100 L milk pasteurizer.
- Material: Stainless steel
- Heating power, kW: 24
- Volume: 150l/ 300l/ 500l
The professional yogurt making machine is designed to produce a wide range of yogurt production, e.g. creamy, liquid drinking, greek, white, organic, fruit yogurts. The machine can be used by farms and small dairy factories.
- Material: Stainless steel
- Principle of operation: Batch mode
MIP Y Pasteurizers are designed for the thermal processing of milk, for the production of yoghurt, white cheese (feta), hard cheese, ice cream and many other milk products.
- Material: Stainless steel
- Volume: 50l/ 100l/ 200l/ 300l/ 400l/ 500l/ 650l
Pasteurizers are used for the heat treatment (pasteurization) of juice before it is filled into bottles, containers or other types of packaging. Its compact, space-saving design and simple operation make it suitable for various production facilities.
- Productivity: 400 l
- Material: Stainless steel
- Heating power, kW: 36
- Country of origin: EU
- Voltage: 380-400V
The plate pasteurizer is designed for partial decrystallization and pasteurization of honey preheated to a temperature of 30-35 degrees.
- Principle of operation: Continuous mode
- Country of origin: EU
The device is designed for the pasteurization of a wide range of products in various types of packaging material such as cans and jars.
- Heating: Mixed
- Productivity: 300 l 400 l 500 l
- Material: Stainless steel
- Principle of operation: Batch mode
- Type of equipment: Individual machine
The tubular pasteurizer is typically designed for pasteurizing cream in butter production lines. These pasteurizers are commonly used in dairy processing industrial facilities, especially in butter production and other related sectors.
- Material: Stainless steel
- Principle of operation: Continuous mode
- Country of origin: Slovakia
A vat or cooking kettle for milk is a large container or vessel used for heating and processing milk, typically in dairy production, to pasteurize, cook, or produce various dairy products such as cheese or yogurt.
- Material: Stainless steel
- Principle of operation: Batch mode
- Volume: 500l/ 1000l
The pasteurization equipment MGGP is suitable for the heat treatment of low viscosity foods as well as drinking water.
- Productivity: 500 l
- Material: Stainless steel
- Principle of operation: Continuous mode
We offer many different types of pasteurizers.
- Material: Stainless steel
- Principle of operation: Continuous mode
- Type of equipment: Individual machine
- Country of origin: Slovakia
A milk pasteurizer is designed for quick and effective pasteurization of milk, where the heating of the product in the working container is achieved by supplying hot water into the jacket.
- Special mixing device
- Large outlet valve at the lowest point of the pasteurizer
- Insulation of the working container to reduce heat loss during pasteurization
- Compact installation
- The control panel is located directly on the unit's body
- Material: Stainless steel
- Principle of operation: Batch mode
- Volume: 100l/ 300l
Pasteurizer, cheese boiler is designed for processing milk, yogurt, fruit juice or other liquids.
- Material: Stainless steel
- Heating power, kW: 12/ 18/ 24
- Volume: 200l/ 300l/ 500l
We offer different pasteurizers for different applications.
- Heating: Gas
- Productivity: 300 l
- Material: Stainless steel
- Operation mode: Automatic
- Principle of operation: Continuous mode
- Country of origin: EU
- Voltage: 220-230V
We offer different types of dairy pasteurizers. Tell us if you are producing cheese, milk, yoghurt or ice cream and we will help you pick the right pasteurizer for you.
- Material: Stainless steel
- Principle of operation: Batch mode
- Country of origin: EU
- Volume: 200l/ 300l/ 500 l/ 800 l / 1000l
Tell us if you are producing cheese, milk, yoghurt or ice cream. The difference between the milk pasteurizer and the yoghurt pasteurizer is that the yoghurt pasteurizer is equipped with a detachable arm with a detachable big stirrer and two half lids.
- Material: Stainless steel
- Country of origin: EU
- Volume: 50l/ 100l/ 200l/ 300l/ 400l/ 500 l/ 650l 800 l / 1000l/ 1250l/ 1500l
Unbeatable price for highest quality material, modern technology, cylinder design. We offer different capacity catering cookers, electric, steam or gas.
- Heating: Steam
- Material: Stainless steel
- Volume: 150l/ 200l
Unbeatable price, excellent cooking results, designed to be placed in tight spaces where sharp edges or corners may create problems. We have different capacities boiling cookers.
- Material: Stainless steel
- Heating power, kW: 18
- Volume: 150l
- Voltage: 380-400V
Electric pasteurizer suitable for pasteurizing beverages as well as filling up bottles or bag-in-boxes. We offer 3 production capacities. The basic pasteurizer model comes without the manual BiB filler module.
- Productivity: 180 l/h / 300l
- Material: Stainless steel
- Principle of operation: Continuous mode
- Voltage: 380-400V
The pasteurizer equipment MGGP is suitable for the heat treatment of low viscosity liquids as well as drinking water.
- Productivity: 500 l/h/ 800 l/h
- Material: Stainless steel
- Principle of operation: Continuous mode
For a price quote or for a free consultation, send us a request.
- Productivity: 90l
- Material: Stainless steel
- Heating power, kW: 6/
- Principle of operation: Continuous mode
- Voltage: 380-400V
Pasteurization dipping tub is suitable for the heat treatment of packaged fruit preparations, (jams, fillings, hams) or fermented preparations (vinegar, beer) and pickles to preserve them, and to eliminate harmful microorganisms.
- Material: Stainless steel
- Principle of operation: Batch mode
- Volume: 100l/ 200l/ 300l
