Milk pasteurizer VAR E
A milk pasteurizer is designed for quick and effective pasteurization of milk, where the heating of the product in the working container is achieved by supplying hot water into the jacket.
- Special mixing device
- Large outlet valve at the lowest point of the pasteurizer
- Insulation of the working container to reduce heat loss during pasteurization
- Compact installation
- The control panel is located directly on the unit's body
Milk pasteurizers can also be supplied with water heaters as an optional feature - these are external sources of hot water supply. The pasteurizer can also be used as a milk cooler if cold water is supplied to the unit's jacket from an external ice water station with a chiller (optional).
Suitable for heating, preheating, pasteurizing milk up to 95-98 degrees, as well as cooling milk when using a cold coolant. The installation serves as a universal solution for small milk processing plants, as it can change its functional properties depending on the coolant supplied into the jacket.
Suitable for the pasteurization or cooling of products such as:
|
|
|
|
Advantages:
- The unit is composed of high-quality materials made in Europe.
- The pasteurizer is made entirely out of food grade stainless steel AISI 304.
- 3-layer casing with thermal insulation and an external decorative casing.
- Temperature sensor for adjusting and monitoring the heat treatment temperature.
- The inclined paddle mixer is the ideal solution for both pasteurization and cooling of milk.
- Possibility of connecting a refrigeration unit and using the pasteurizer as a cooling tank for milk.
Basic Version
It comprises a three-layer stainless steel tank with thermal insulation, into the jacket of which coolant can be supplied under a pressure of up to 0.5 bar for indirect heating or cooling of the product. The pasteurizer is equipped with an inclined paddle mixer with an electric drive, a control panel, and height-adjustable legs.
Heating is carried out by supplying coolant into the jacket from an external source for heating or cooling, which can be offered as an additional option.
Operating Principle
Mixing of the product is ensured by an inclined paddle mixer. The upper housing opens by 1/3 using a hatch for loading raw materials. The finished product is discharged through a release valve located at the lowest hydraulic point
Options
- electric flow water heater
- steam generator
- Material: Stainless steel
- Principle of operation: Batch mode
- Volume: 100l/ 300l
You might also like
Electric heating panel with three different power possibilities: 12, 24 and 48 KW – excellent product manufactured by people who perfectly know the secret of product storage, maintenance and processing.
- Heating power, kW: 12/ 24/ 48
- Country of origin: EU
The generator is mounted on a stainless steel platform support, covered with stainless steel AISI 304 properly shaped with electrical and water connections already made. Stainless steel cocks AISI 316, malleable iron pipe fittings, feed water pump (mod. TP78A CALPEDA) with 1 stainless steel non-return valve, with VITON seal.
- Heating power, kW: 24/ 32/ 48
Pasteurizers are used for the heat treatment (pasteurization) of juice before it is filled into bottles, containers or other types of packaging. Its compact, space-saving design and simple operation make it suitable for various production facilities.
- Productivity: 400 l
- Material: Stainless steel
- Heating power, kW: 36
- Country of origin: EU
- Voltage: 380-400V
Pasteurization dipping tub is suitable for the heat treatment of packaged fruit preparations, (jams, fillings, hams) or fermented preparations (vinegar, beer) and pickles to preserve them, and to eliminate harmful microorganisms.
- Material: Stainless steel
- Principle of operation: Batch mode
- Volume: 100l/ 200l/ 300l
The MAK Milk pasteurizer is a 100-liter, double-walled batch processing unit designed for heating and stirring milk and other liquid or semi-liquid dairy products. The unit employs a combined heating system: direct electric heating at the base (6.5 kW power) transferring heat through a multi-layer ("sandwich") bottom, and gentle indirect air heating across the entire cylindrical surface of the processing vessel. The special double-walled design also significantly reduces heat loss and enhances operator safety.
- Agitator attachment features scrapers for the vessel bottom and walls, ensuring continuous product movement across heated surfaces.
- Interchangeable mixer attachment system allowing for the quick replacement of a scraper mixer with a cheese curd cutting blade (optional).
- Available with either manual six-stage heating control or an automatic digital PID temperature controller, timer, with adjustable stirring speed.
- Material: Stainless steel
- Heating power, kW: 6,5
- Principle of operation: Batch mode
- Country of origin: Slovakia
- Volume: 100l
The device is designed for the pasteurization of a wide range of products in various types of packaging material such as cans and jars.
- Heating: Mixed
- Productivity: 300 l 400 l 500 l
- Material: Stainless steel
- Principle of operation: Batch mode
- Type of the equipment: Individual machine
Electric pasteurizer suitable for pasteurizing beverages as well as filling up bottles or bag-in-boxes. We offer 3 production capacities. The basic pasteurizer model comes without the manual BiB filler module.
- Productivity: 180 l/h / 300l
- Material: Stainless steel
- Principle of operation: Continuous mode
- Voltage: 380-400V
The tubular pasteurizer is typically designed for pasteurizing cream in butter production lines. These pasteurizers are commonly used in dairy processing industrial facilities, especially in butter production and other related sectors.
- Material: Stainless steel
- Principle of operation: Continuous mode
- Country of origin: Slovakia
The professional cooking vat is designed for dairy products processing. The machine can be used by farms and small dairy factories.
Please check out the new updated version of our 100 L milk pasteurizer.
- Material: Stainless steel
- Heating power, kW: 24
- Volume: 150l/ 300l/ 500l
Pasteurizer, cheese boiler is designed for processing milk, yogurt, fruit juice or other liquids.
- Material: Stainless steel
- Heating power, kW: 12/ 18/ 24
- Volume: 200l/ 300l/ 500l
We offer different types of dairy pasteurizers. Tell us if you are producing cheese, milk, yoghurt or ice cream and we will help you pick the right pasteurizer for you.
- Material: Stainless steel
- Principle of operation: Batch mode
- Country of origin: EU
- Volume: 200l/ 300l/ 500 l/ 800 l / 1000l
The pasteurization kettle with manual tilting is a modern device designed for gentle heat treatment of milk and dairy products, which allows for their effective pasteurization, extends shelf life and increases safety, while preserving the original taste and nutritional values. The 6-stage heating regulation of the powerful integrated heater, allows the milk to be reliably pasteurized directly in the container with a sandwich bottom, ensuring even heat distribution.
- Ideal solution for small-scale and home production of dairy products
- Removable lid for easy inspection and manual mixing of the product
- Option to equip it with a drain valve for discharging liquid products
- Even heating without burning thanks to the sandwich bottom
- Easy connection to a single-phase 230 V power supply
- Material: Stainless steel
- Heating power, kW: 2,6 / 6,5
- Volume: 30l/ 50l/ 100l
- Voltage: 380-400V
Unbeatable price, excellent cooking results, designed to be placed in tight spaces where sharp edges or corners may create problems. We have different capacities boiling cookers.
- Material: Stainless steel
- Heating power, kW: 18
- Volume: 150l
- Voltage: 380-400V
The cheese boiler is used in the dairy industry for the production of cheese grains during the production of natural hard, semi-hard, soft cheeses, and other cheese or curd products. The cheese maker is equipped with a special knife-mixer (lyre) for cutting the cheese curd. Suitable for both small and large scale production. Using this cheese-cooking boiler you can also pasteurize other dairy products, produce yogurt, cottage cheese kefir, fermented baked milk, varenets, sour cream and more.
- Material: Stainless steel
- Operation mode: Automatic
- Principle of operation: Batch mode
- Country of origin: Slovakia
- Working volume: 300 l
A vat or cooking kettle for milk is a large container or vessel used for heating and processing milk, typically in dairy production, to pasteurize, cook, or produce various dairy products such as cheese or yogurt.
- Material: Stainless steel
- Principle of operation: Batch mode
- Volume: 500l/ 1000l
The Batch Pasteurizer BP 400 is designed for controlled heat treatment of food products in batch production, including vegetables, fruits, sauces, ready-made foods, and products packed in jars. Two 200-liter baths with automatic temperature control provide flexible and repeatable pasteurization, while the basket system and electric crane ensure convenient product handling.
- Two separate 200-liter pasteurization baths
- Automatic temperature control
- Suitable for jars, containers, and loose food products
- Suitable for vegetables, fruits, mushrooms, sauces, preserves, and ready-made foods
- Electric crane for convenient basket handling
- Maximum heating temperature of 90°C
- Easy-to-clean stainless-steel construction
- Separate bath heating available as an option
- Heating power, kW: 48
- Type of the equipment: Individual machine
- Country of origin: EU
- Weight: 300 kg
- Voltage: 380-400V
- Geometric volume: 400 l
The professional yogurt making machine is designed to produce a wide range of yogurt production, e.g. creamy, liquid drinking, greek, white, organic, fruit yogurts. The machine can be used by farms and small dairy factories.
- Material: Stainless steel
- Principle of operation: Batch mode
MIP Y Pasteurizers are designed for the thermal processing of milk, for the production of yoghurt, white cheese (feta), hard cheese, ice cream and many other milk products.
- Material: Stainless steel
- Volume: 50l/ 100l/ 200l/ 300l/ 400l/ 500l/ 650l
